Saklar Schneider Vivace -2 way switch 16 AX 250 V -1 module- White [KB34S_1_WE_G3]
Rp91.818
Deskripsi
Specifications
| Range | Vivace |
|---|---|
| Product or component type | Switch |
| device short name | KB34 |
| Device application | Control switch |
| Additional switch application | On/off switching |
| Number of rocker | 4 |
| Switch function | 1-way |
| Colour tint | White |
| Technology type | Electromechanical |
|---|---|
| Device presentation | Complete product |
| Actuator | Rocker |
| Number of gangs | 4 gangs |
| Colour tint | White |
| Material | Polycarbonate: grid plate Polycarbonate: surround Nylon: base Polycarbonate: dolly Nylon: actuator Silver plated copper: bridge Brass: terminal cover |
| Surface finish | Glossy |
| Surface treatment | Untreated |
| [Ue] rated operational voltage | 220…250 V |
| Type of packing | Plastic bag |
| Network type | AC |
| Quantity per set | 1 |
| Sale per indivisible quantity | 1 |
| Rated current | 10 AX |
| Projecting depth | 8 mm |
| device mounting | Flush |
| Mounting support | Wall mounted |
| Fixing mode | By screw M3.5 |
| Fixing center | 60.3 mm |
| Connections – terminals | Screw terminal |
| Embedding depth | 25 mm |
| Number of terminals | 8 |
| Rated current | 10 AX at 250 V AC, inductive 10 AX at 250 V AC, fluorescent 10 A at 250 V AC, resistive |
| [Ue] rated operational voltage | 250 V AC |
| Network frequency | 50/60 Hz |
| Contacts material | Brass and phosphor bronze |
| Connections – terminals | 8 screw terminals |
| Terminal identifier | L2 COM L1 |
| Tightening torque | 0.4 N.m |
| Clamping connection capacity | <= 2.5 mm² for rigid or stranded cable(s) |
| Wire stripping length | 12 mm |
| Dielectric strength | 2000 V |
| Minimum load breaking capacity | 200 operations 1.25 In and 1.1 Un |
| Width | 86 mm |
| Height | 86 mm |
| Depth | 37 mm |
| Product weight | 0.0829 kg |
| standards | IEC 60669 |
|---|---|
| Product certifications | SNI |
| Ambient air temperature for operation | -5…40 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0…2000 m |
| Environmental characteristic | Indoor use |
| IP degree of protection | IP20 |
