Advantech Network Appliance,Haswell-EP 2U,8 NMC-latch (FWA-6520-03E)
Deskripsi
| Category | Attribute | Value |
| I/O | Console port | 1 |
| I/O | Others | 1 x power button |
| I/O | USB3.0 | 2 |
| Memory | ECC Support | Yes |
| Memory | Max. Capacity | 256GB (CPU0x8,CPU1x8) |
| Memory | Socket | 16 x 288-pin RDIMM |
| Memory | Technology | DDR4, 2133/2400MHz |
| Storage | 2.5″ HDD/SSD | Max. 2 x 2.5″ HDD/SSD |
| Storage | mSATA SSD | 2 x mSATA |
| Environment | Non-operating Temperature | -20 ~ 80° C (-4 ~ 167° F) and 40° C @ 95% RH Non-Condensing humidity |
| Power | Connector | AC 3pin plug |
| Power | Input | 100 V ~ 240 V |
| Power | Power Type | AC, redundant DC, redundant (optional) |
| Power | Watts | 820W |
| Processor System | BIOS | AMI EFI 64 Mbit |
| Processor System | Chipset | C612 |
| Processor System | Core Number | 8C/10C/12C/14C/16C/18C/20C/22C |
| Processor System | Frequency | 2.0GHz/2.1GHz/2.2GHz/2.3GHz/2.4GHz/2.6GHz |
| Processor System | L2 Cache | 30MB ~ 55 MB |
| Processor System | Processor | 2 x Intel® Xeon® E5-2600 v3 / v4 Socket R3 |
| Cooling | Cooling | 3x system FAN with smart FAN |
| Certification | CE/FCC/CB/UL/CCC | |
| Expansion | NMC | 8 NMCs |
| Expansion | PCIe x 16 | N/A |
| Mechanical | Construction | Iron |
| Mechanical | Dimensions (W x H x D) | 430 x 88x 558 mm (16.9″ x 3.4″ x 22″) |
| Mechanical | Mounting | 2U Rackmount |
| Mechanical | Weight | 20 kg |
| Environment | Operating Temperature (air flow 0.7 m/sec) | 0 ~ 40 °C (32 ~ 104 °F) |
| Environment | Shock Protection | with SSD: 10G, IEC-60068-2-27, half sine, 11ms duration |
| Environment | Vibration Resistance | with SSD: 0.3 Grms, IEC 60068-2-64, 5-500Hz, 1hr/axis |
| OS Support | Linux (CentOS, Red Hat, Ubuntu) | |
| IPMI | IPMI | IPMI v2.0 compliant BMC with web interface (AMI MegaRAC SP-X) |
| Virtualization | VT-x | VT-x |
| Networking | 1GbE | 2 x 10/100/1000 Mbps RJ45 via Intel® I210 chip |
| Networking | Controller | 1 x Intel® I210 |
| Networking | LAN bypass Advanced | LBP support by NMC |
| Networking | LAN bypass Legacy | – |
| Advantech S/W Packages | Individual Package | Advanced LBP Library |
| Advantech S/W Packages | QuickStart Linux Image | IPMI Tool, LCD4Linux, Advanced LBP Utility |
| LCD Module | LCD Module | 16 x 2 graphic display, 5 buttons |
